Haro Double Peak
Double Peak, a series inspired by a local spot not far from Haro utilizes a low stand over, low center of gravity designed frame made from 6000 series alloy, an internal head tube, and internal cable routing to keep things clean and tucked away. DP Sport features a 24speed drive train commanded by Shimano’s Easy Fire 3×8 speed shifters. It glides along on XM-2 double wall rims, stainless spokes and finished with Kenda Honey badger 27.5″ x 2.2″ tires. The front end features a Suntour XCT 100mm fork and has a hydraulic lockout ready when desired. The Sport likes to go fast, but it can stop on a dime thanks to Shimano’s M-315 Hydraulic disc brake set.
- Double Peak 6000 Series alloy frame w/ internal routing
- Suntour XCT 100mm travel fork w/ hydraulic Lockout
- Shimano TY-301 42/34/24T crankset
- Shimano TY-700 front & Altus rear derailleurs
- Shimano HG-200 8-spd 12-32T cassette
- Weinmann XM-2 alloy DW rims
- New Shimano ST-EF505 Easy Fire 3×8-spd shifters
- New Shimano ST-EF505 / M-315 hydraulic brakeset
- Kenda Honey Badger XC 2.2″ tires
Break out of the concrete jungle on the full-featured Double Peak 27.5″/29″ Sport. We start with the new 2017 Haro Double Peak 6000-series aluminum frame engineered with an easy-riding low standover height and center of gravity. Next we pile on the high-function features: Suntour XCT 100mm travel fork w/ hydraulic lockout, Tektro Aries mechanical disc brakeset, 24-speed Shimano Altus drivetrain, and cross-country favorite light ‘n grippy Kenda Honey Badger tires. So you’ll be ready to plan your escape to fresh air and challenging fun.
Specifications
| Frameset | |
|---|---|
| Frame | Double Peak 29″ 6061 T6 oversized aluminum w/ semi-integrated headtube |
| Fork | SR Suntour XCT 29″, 100mm travel w/ hydraulic lock out |
| Colors | Silver / Red, Black / White |
| Drivetrain | |
| Cranks | SR Suntour XCC 102, 42/34/24 |
| Pedals | Nylon ATB |
| Chain | KMC Z51 |
| Bottom Bracket | Sealed cartridge |
| Front Derailleur | Shimano TX-50 |
| Rear Derailleur | Shimano TX-35 |
| Derailleur Shifter | Shimano EF-41 EZ Fire, 7 speed |
| Freewheel/Cassette | Shimano HG-20, 7 speed cassette, 12-32 |
| Wheels | |
| Tires | H-5120, 29 x 2.1″ |
| Wheels/Rims | Weinmann ZAC-19 32h rims, Pivit alloy disc cassette hubs, stainless steel spokes |
| Braking System | |
| Brakes | Tektro Aries mechanical disc brakes w/ 160 front rotor, 160mm rear rotor |
| Brake Levers | Shimano EF-41 |
| Other Components | |
| Grips | Dual density |
| Handle Bar | Pivit riser bar, 25mm rise, 680mm width, 31.8mm clamp |
| Stem | Pivit forged alloy, 10 degree rise |
| Headset | FSA # 10 semi-integrated |
| Saddle | Haro Sport |
| Seat Post | Pivit alloy micro adjust, 31.6 x 350mm |
| Seat Clamp | Pivit alloy 34.9 quick release |
Get off the beaten path and get a little crazy with the Double Peak 27.5″/29″ Trail, a playful 6000-series aluminum hardtail mountain bike in the do-everything-right 27.5/29″ wheel size. Go ahead and get rowdy, your upgraded Tektro Auriga Hydraulic disc brakes, 27-speed drivetrain and Weinmann XM-25 Disc alloy double wall rims have got your back.
Specifications
| Frameset | |
|---|---|
| Frame | 2017 Haro Double Peak 27.5″ 6000 Series Alloy, w/ Chainstay Disc Brake Mount |
| Fork | Suntour XCT HLO, 100mm Travel, Post Mount, w/ Hydraulic Lockout |
| Colors | SG Blue, SG Charcoal |
| Drivetrain | |
| Cranks | SR Suntour XCT-414 42/34/24t |
| Pedals | FPD Platform, Nylon Body, Crmo Axles |
| Chain | KMC X9 1/2″ X 3/32″ |
| Bottom Bracket | SR Suntour BB10-XCT Sealed Cartridge |
| Front Derailleur | Shimano Altus M370 |
| Rear Derailleur | Shimano Acera 9-Spd |
| Derailleur Shifter | Shimano SL-M370 3×9-Spd |
| Freewheel/Cassette | Shimano HG-200 9-Spd 11-34t |
| Wheels | |
| Tires | Kenda Honey Badger XC 27.5×2.05″ |
| Wheels/Rims | Weinmann XM-25 Disc Alloy DW 32h Rims, Pivit Alloy Disc Cassette Hubs |
| Braking System | |
| Brakes | Tektro Auriga HD-M285 Hydraulic, 160mm Rotors |
| Brake Levers | Tektro Auriga |
| Other Components | |
| Grips | WTB Trail II |
| Handle Bar | Pivit Alloy 25mm Riser Bar 31.8mm |
| Stem | Pivit Alloy Stem |
| Headset | FSA No. 10P, 1-1/8″ Threadless For 50mm OD Head Tube; w/ 15mm Top Cover |
| Saddle | Haro Double Peak |
| Seat Post | Pivit Alloy Micro Adjust 31.6mm |
| Seat Clamp | Pivit Alloy 34.9mm Quick Release |
Geometry
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach |
| 16 | 72° | 73° | 592 | 405 | 455 | 60 | 1088 | 791 | ||
| 18 | 72° | 73° | 601 | 460 | 455 | 60 | 1098 | 821 | ||
| 20 | 72° | 73° | 616 | 510 | 455 | 60 | 1106 | 849 | ||
| 22 | 72° | 73° | 623 | 559 | 455 | 60 | 1116 | 875 |
How To Buy
| brands | Haro |
|---|---|
| PC / Model | Double Peak 27.5 Sport, Double Peak 27.5 Trail, Double Peak 29 Trail, Double Peak Sport 29 |
| size | 14", 16", 18", 20", 22" |
