Haro Double Peak 29er Trail Mountain Bike
FEATURES
- Double Peak 6000 Series alloy frame w/ internal routing
- New Suntour XCT 100mm travel fork w/ hydraulic Lockout
- Shimano MT-100 40x30x22T crankset
- Shimano Altus M2000 front derailleur & shifters
- Shimano Acera 9-spd rear derailleur
- Shimano HG-200 9-spd 11-36T cassette
- Weinmann U-26 Disc alloy DW rims
- Shimano 315 hydraulic disc brakeset
aro Double Peak 29er Trail Mountain Bike
Double Peak 29 Trail utilizes a low stand over, low center of gravity designed frame made from 6000 series alloy, an internal head tube, and internal cable routing. DP Trail 29 features a 27speed upgraded drive train, versatile and capable of handling a wider variety of terrain. It glides along on 29″ U-26 double wall rims, stainless spokes and finished with Kenda Honey badger 29″ x 2.2″ tires. The front end features a Suntour XCT 100mm fork with hydraulic lockout. The Trail appreciates speed, but it can stop on a dime thanks to a Shimano’s M-315 Hydraulic disc brake set.
SPECIFICATIONS
FRAMESET | |
Frame | 2018 Haro Double Peak 29.0″ 6000 series alloy, w/ Internal housing routing & chainstay disc brake mount |
Fork | 2018 SR Suntour XCT 100mm travel w/ hydraulic lockout |
Colors | Black / Charcoal, Aqua / Black |
Weight | 32.20lbs |
DRIVETRAIN | |
Cranks | Shimano FC-MT100 40/30/22T |
Pedals | FPD Nylon body, Crmo axles,Platform |
Chain | KMC X9 1/2″X3/32″ |
Bottom Bracket | Shimano Sealed cartridge |
Front Derailleur | 2018 Shimano Altus, FD-M2000, 3×9-spd, Top Swing |
Rear Derailleur | 2018 Shimano Acera 9-spd RD-M3000 |
Derailleur Shifter | 2018 Shimano Altus SL-M2000, 3×9-spd |
Freewheel/Cassette | Shimano HG-200 9-spd 11-36T |
WHEELS | |
Tires | Kenda Honey Badger XC 29.0*2.2 |
Wheels/Rims | Weinmann U-26 Disc alloy double wall, Pivit alloy disc cassette 32h hubs |
BRAKING SYSTEM | |
Brakes | Shimano BR-M315 hydraulic, 160mm rotors |
Brake Levers | Shimano BL-M315 |
OTHER COMPONENTS | |
Grips/Tape | WTB Trail II |
Handle Bar | Pivit alloy 15mm riser bar 31.8mm |
Stem | Pivit melt forged stem |
Headset | 1-1/8″ Threadless for 50mm OD headtube; w/ 15mm top cover |
Saddle | Haro Double Peak |
Seat Post | Pivit alloy micro adjust 31.6mm |
Seat Clamp | Pivit alloy 34.9mm quick release |
GEOMETRY & SIZING
To read more about how Haro MTB’s fit and geometry
are created visit our Bicycle Fit Tips page.
SIZE | S / 16.5 | M / 18 | L / 20 | XL / 22 |
A. Seat Tube (C-T) | 419 | 457 | 508 | 559 |
B. Top Tube (Effective) | 595 | 612 | 620 | 630 |
C. Head Tube Angle | 70.5 | 71 | 71 | 71 |
D. Seat Tube Angle | 72.5 | 72.5 | 72.5 | 72.5 |
E. Chainstay Length | 450 | 450 | 450 | 450 |
F. BB Drop | 64 | 64 | 64 | 64 |
G. Wheelbase | 1091 | 1102 | 1111 | 1121 |
H. Head Tube Length | 100 | 100 | 110 | 120 |
I. Standover | 750 | 754 | 775 | 798 |
J. Stack Height | 631 | 633 | 643 | 652 |
K. Reach | 396 | 412 | 417 | 424 |
L. Fork Height | 515 | 515 | 515 | 515 |
M. Fork Offset | 46 | 46 | 46 | 46 |
N. Stem Length | 70 | 70 | 90 | 90 |
O. Bar Width | 680 | 700 | 700 | 700 |
P. Crank Length | 170 | 175 | 175 | 175 |
