Hikvision DS-7600NI-E2 Plug and Play NVR
Availability:
In stock
PRODUCT HIGHLIGHTS
- Individually Configurable Channels
- Third-Party Network Cameras Supported
- Up to 5MP Resolution Recording
- HDMI and VGA Output at Up to 1080p
- 2 SATA Interfaces (Up to 4TB Each)
- Pre-Installed 2TB HDD
- 2-Way Audio Input; 1x RCA Output
- Configurable Video Input/Output Quality
- HDD Group Management
HIKVISION NVR (Network Video Recorder) DS-7604NI-E1/4P / DS-7600NI-E2/8P (16P) series
DS-7600NI-E1/4P and DS-7600NI-E2/8P (16P) series NVR (Network Video Recorder) is a new generation recorder developed by Hikvision independently. Combined with multiple advanced technologies, such as audio and video decoding technology, embedded system technology, storage technology, network technology and intelligent technology. It can both work alone as a recorder and cooperate with other device to form a comprehensive surveillance system.
The DS-7600NI-E1/4P and DS-7600NI-E2/8P (16P) series NVR are widely applied in the areas of finance, public security, military, communication, transportation, education, etc.
• Connectable to the third-party network cameras like like ACTI, Arecont, AXIS, Bosch, Brickcom, Canon, ONVIF, PANASONIC, Pelco, PSIA, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO.
• 4/8/16/32 network cameras can be connected for different models.
• Support live view, storage, and playback of the connected camera with up to the resolution of 6 megapixels.
• Simultaneous HDMI and VGA outputs at up to 1920×1080 resolution.
• New GUI and support starting record with one key.
• Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm, and VCA.
• Realize instant playback for assigned channel during multi-channel display mode.
• Customization of tags, searching, and playing back by tags.
• Playback by sub-periods.
• Locking and unlocking record files.
• Support HDD quota mode; different capacity can be assigned to different channel.
• Up to 2 SATA hard disks can be connected with up to 6TB capacity for each.
• 1 self-adaptive 10M/100M/1000M network interface is provided.
• Up to 4/8/16 independent PoE network interfaces for different models.
• Support Hikvision DDNS (Dynamic Domain Name System).
• Support network detection, including network delay, packet loss, etc.
• Support VCA detection alarm and VCA search.
• 4/8/16/32 network cameras can be connected for different models.
• Support live view, storage, and playback of the connected camera with up to the resolution of 6 megapixels.
• Simultaneous HDMI and VGA outputs at up to 1920×1080 resolution.
• New GUI and support starting record with one key.
• Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm, and VCA.
• Realize instant playback for assigned channel during multi-channel display mode.
• Customization of tags, searching, and playing back by tags.
• Playback by sub-periods.
• Locking and unlocking record files.
• Support HDD quota mode; different capacity can be assigned to different channel.
• Up to 2 SATA hard disks can be connected with up to 6TB capacity for each.
• 1 self-adaptive 10M/100M/1000M network interface is provided.
• Up to 4/8/16 independent PoE network interfaces for different models.
• Support Hikvision DDNS (Dynamic Domain Name System).
• Support network detection, including network delay, packet loss, etc.
• Support VCA detection alarm and VCA search.
Video/Audio Input | ||
---|---|---|
IP video input: | | | 8-ch |
Two-way audio input: | | | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
Network | ||
Incoming bandwidth: | | | 80Mbps |
Outgoing bandwidth: | | | 80Mbps |
Remote connection: | | | 128 |
Video/Audio Output | ||
HDMI/VGA output: | | | 1-ch, resolution: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
Recording Resolution: | | | 6Â MP/5Â MP/4Â MP/3Â MPÂ 1080p/UXGA/720p/ VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Frame Rate: | | | Main stream: 50 fps (P) / 60 fps (N) Sub-stream: 50 fps (P) / 60 fps (N) |
Audio Output: | | | 1-ch, RCA (Linear, 1kΩ) |
Synchronous Playback: | | | 8-ch |
Decoding | ||
Live view / Playback: | | | 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Capability: | | | 8-ch@720P, 6-ch@1080P |
Hard Disk | ||
SATA: | | | 2 SATA interfaces for 2 HDDs |
Capacity: | | | Up to 4TB for each disk |
External Interface | ||
Network Interface: | | | 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
USB Interface: | | | 1 × USB 2.0 and 1 × USB 3.0 |
Alarm In: | | | 4-ch |
Alarm Out: | | | 1-ch |
POE | ||
Interface: | | | 8 independent 100 Mbps PoE network interfaces |
Max. Power: | | | 120W |
Supported Standard: | | | AF and AT |
General | ||
Power Supply: | | | 100~240VAC |
Consumption(without hard disk and POE): | | | ≤ 10W |
Working Temperature: | | | -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
Working Humidity: | | | 10Â %Â ~Â 90Â % |
Chassis: | | | 19-inch rack-mounted 1U chassis |
Dimensions: | | | 445 × 290 × 45mm (17.5 ×11.4 × 1.8 inch) |
Weight(without HDD): | | | ≤ 1 Kg (2.2 lb) |
How To Buy
brands | Hikvision |
---|---|
PC / Model | DS-7604NI-E1, DS-7608NI-E1, DS-7608NI-E2, DS-7616NI-E1, DS-7616NI-E2/16P |
