Emmy Mount DF400 Full Motion Cantilever Mount
Features
- Fits TV screen 32 to 47 inches with load up to 60 lbs
- VESA compliance from 100x100mm to 400x400mm
- Ultra-Slim full motion articulating cantilever mount extends from 2.2″ to 19.7″ from the wall
- Swivel 100-140 degrees, tilt angle between -5 and +8 degrees
- Screen level adjustable, integrated cable management
NB Emmy Mount DF400 Full Motion Cantilever Mount for Flat Panel TV Screens 32 to 52 Inches up to 60 lbs
Overview
DF400 TV Mount/ DF-400 (DF400) Full Motion TV Mount for TV up to 52″
| TV Size: | 32″ – 52″ |
| Weight Limit: | 31.8kg |
| VESA Compliance: | – 100 x 100mm – 200 x 100mm – 200 x 200mm – 400 x 200mm – 400 x 400mm |
| Tilt Angles: | -5° ~ + 8° |
| Swivel: | 160° |
| Cable Management: | No |
| Min. Extension: | 55mm |
| Max. Extension: | 488mm |
| Weight: | |
| Colour: | Black |
| Material: | SPCC |
| Surface Treatment: | Powder Painting Coating Finished |
Product Description
- Fits TV screen 32 to 52 inches with load up to 60 lbs
- VESA compliance from 100x100mm to 400x400mm
- Ultra-Slim full motion articulating cantilever mount extends from 2.2″ to 19.7″ from the wall
- Swivel 100-140 degrees, tilt angle between -5 and +8 degrees
- Screen level adjustable, integrated cable management
Features:>>>
Specifications:>>>
Which mounts will fit my TV?
How can I tell if my TV is VESA compliant?
Although the vast majority of TV’s are VESA compliant, there are some models that are not. Please consult your TV product manual for more information. Most manuals indicate the exact VESA standard necessary for mounting, or simply indicate the VESA mounts are supported in general. If this is the case, simply purchase a wall mount within the TV size guidelines of your TV.
What is VESA?
VESA is a set of standards for the manufacturing of flat screen televisions and PC monitors. Most manufacturers comply with this standard by adhering to an industry wide “hole pattern” on the back of their displays for mounting purposes. A VESA hole pattern is measured in both horizontal and vertical distance between mounting holes. For example, VESA 75 x 75 means your TV mounting holes are 75mm apart horizontally and 75mm apart vertically.
How do I measure my TV’s VESA standard?
Look for the 4 mounting holes on the back of your flat screen television. Take both a horizontal and vertical measurement (in mm). This is your VESA Standard. For help, see the diagrams below:
