Fanvil X6 Enterprise IP Phone

Availability: In stock
KShs16,000.00

Fanvil X6 6-Line Gigabit PoE IP Phone

  • Support 6 SIP lines
  • HD Voice
  • Tri-color screen (main + 2 DSS)
  • Dual Gigabit ports
  • 60 DSS keys
  • Can add optional Bluetooth USB dongle to support Bluetooth
  • Desktop installations. (NOT wall-mountable)
  • Support PoE (Power over Ethernet) – optional external power supply not included
  • Industrial standard certificate: CE/FCC
  • Please see Fanvil X6 datasheet for full spec
Compare

Fanvil X6 Enterprise IP Phone

Fanvil X6 IP Phone features a 4.3″ main color screen and two 2.8″ DSS screen for a smart and friendly user interface. The X6 carry the function of LCD extension module, with 12 DSS keys corresponded to the LCD display to provide dynamic DSS/BLF functions up to 5 pages at virtualized total 60 keys. The 1x USB port so you can add an optional Bluetooth USB dongle for bluetooth connectivity. X6 also support use of wireless headsets – add an optional Plantronics APD-80 EHS cable (not included) to use with compatibile Plantronics wireless headsets.

All in One – SIP Phone with DSS Extension Module
The Fanvil X6 also saves you money since there is no need to purchase an expansion module. The X6 comes complete with 12 DSS keys, which correspond to the LCD display to provide dynamic DSS/BLF functions of up to 60 DSS keys.

All in One - SIP Phone with DSS Extension Module

3 x Colour screens
The X6 combines an existing enterprise UI with a colour LCD. It has a 4.3 inch main colour screen, as well as 2 x 2.8 inch DSS screens.
3 x Colour screens

Bluetooth/EHS Support

The X6 supports both Bluetooth headsets, through a USB Dongle, and EHS wireless headsets.

Bluetooth/EHS Support

3CX Certified

Fanvil X6 – Technical Specifications

Generic

  • 6 SIP Lines
  • HD Voice
  • PoE Enabled
  • 3 LCDs (Main + DSS)
  • Handset(HS) / Hands-free(HF) / Headphone(HP) mode
  • Intelligent DSS Keys
  • Desktop / Wall-mount installation
  • Optional External Power Supply
  • Economical and Environmental friendly package
  • Industrial Standard Certifications: CE/FCC

Call Features

  • Call out / answer / reject
  • Mute / Unmute (microphone)
  • Call Hold / Resume
  • Call Waiting
  • Intercom
  • Caller ID Display
  • Speed Dial
  • Anonymous Call (Hide Caller ID)
  • Call Forwarding (Always/Busy/No Answer)
  • Call Transfer (Attended/Unattended)
  • Call Parking/Pick-up (depending on server)
  • Redial
  • Do-Not-Disturb (per line / per phone)
  • Auto-Answering (per line)
  • Voice Message (on server)
  • Local 3-way Conference
  • Hot Line
  • Hot-Desking

Highlights

  • 2 DSS Key-mapping LCD – 12 DSS keys corresponded to the LCD display to provide dynamic DSS/BLF functions up to five pages at virtualised total 60 DSS keys.
  • Gigabit Ethernet – 10/100/1000Mbps Ethernet with PoE enabled.
  • Economic and Environmental Friendly design with Elegant Housing, with high-resolution TFT colour display, delivering a rich visual experience.
  • High Interoperability – Compatible with major platforms: 3CX, Asterisk, Broadsoft, Elastix, Zycoo, etc.

Audio

  • HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
  • Wideband ADC/DAC 16KHz Sampling
  • Narrowband CODEC: G.711a/u, G.723.1, G.726-32K, G.729AB, AMR,iLBC
  • Wideband CODEC: G.722, AMR-WB,
  • Full-duplex Acoustic Echo Canceller (AEC) – Hands-free Mode, 96ms tail-length
  • Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR)
  • Packet Loss Concealment (PLC)
  • Dynamic Adaptive Jitter Buffer up to 300ms
  • DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO

Networking

  • Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
  • IP Configuration: Static / DHCP / PPPoE
  • Network Access Control: 802.1x
  • VPN: L2TP (Basic Unencrypted) / OpenVPN
  • VLAN
  • QoS

Protocols

  • SIP2.0 over UDP/TCP/TLS
  • RTP/RTCP/SRTP
  • STUN
  • DHCP
  • PPPoE
  • 802.1x
  • L2TP (Basic Unencrypted)
  • OpenVPN
  • SNTP
  • FTP/TFTP
  • HTTP/HTTPS
  • TR069

RFCs

  • 354/1321/1350/1769/1889/1890/2131/2132/2616/2617/2
    661/2833/2976/3261/3262/3263/3264/3265/3268/3311/3
    489/3711/4346/4566/5630/
    5865

Deployment & Maintenance

  • Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR069
  • Web Management Portal
  • Web-based Packet Dump
  • Configuration Export / Import
  • Phonebook Import/Export
  • Firmware Upgrade
  • Syslog

Physical Specifications

  • Main LCD x1: 4.3 inch (480×272) LCD colour screen
  • DSS Key-mapping LCD x2: 2.4 inch (240×320) LCD colour screen
  • Keypad: 46 keys, including
    – 4 Soft-keys
    – 8 Function keys
    – 4+1 Navigation keys + OK
    – 12 Standard Phone Digits keys
    – 3 Volume Control keys, Up/Down/Mute (Microphone)
    – 1 Hands-free key
    – 12 DSS Keys with tri-colour LED
    – 1 Page-Switch (PS) key
  • HD Hands-free Speaker (0 ~ 7KHz) x1
  • HD Hands-free Microphone (0 ~ 7KHz) x1
  • HD Handset (RJ9) x1
  • USB Port x1 (Connect with BT USB dongle)
  • Support Bluetooth headset (Through USB Dongle)
  • Support Plantronics Wireless headset (Through Plantronics APD-80 EHS Cable)
  • Standard RJ9 Handset Wire x1
  • 1.5M CAT5 Ethernet Cable x1
  • RJ9 Phone Jacket x2: Handset x1, Headphone x1
  • RJ45 Ethernet Jacket x2: Network x1 , PC x1 (Bridged to Network)
  • Main Chipset: Broadcom
  • DC Power Input: 12V/1A
  • Power Consumption: Idle – ~ W, Peak – ~W
  • Working Temperature: 0 ~ 40℃
  • Working Humidity: 10 ~ 65%
  • Dual-Functional Back Rack x1: Desktop Stand
  • Colour: Black
  • Package Dimensions: 315x270x65mm (W x H x L)
