Tokyowheel™ EPIC 5.6 – Carbon Clincher – Wheelset
Description:
65mm deep rear rim.
Standard Hubs & Spokes
Cassette Compatibility: Shimano/SRAM 8/9/10/11 Speed
One Year Warranty, with wheel replacement for any factory defaults
Tokyowheel™ EPIC 5.6 – Carbon Clincher – Wheelset
EPIC 5.6
All Purpose Aero Wheel System
The best all purpose aero wheelset. Designed to perform great in any conditions, from hill climbs to triathlons, the EPIC 5.6 is great for riders looking for one wheelset to do everything.
Rider Type
Is this wheelset right for you?
Road Racing
The EPIC 5.6 is perfect for a wide variety of road racing situations. It’s a more aerodynamic option than the EPIC 3.4, and performs great in rides and races with a lot of varying conditions. Perfect for longer race stages, criteriums, and for riders looking for an added aerodynamic advantage.
Triathlon
The EPIC 5.6 is the best choice for triathlons in windy conditions. It’s a more crosswind stable wheelset than the EPIC 7.10, and is also great for lighter riders concerned about bike handling. If you are looking for an aero wheelset to use in any training and racing conditions, the EPIC 5.6 is for you.
Recreation
If you are a recreational rider, that rides solo and in a group over a variety of terrain and conditions, the EPIC 5.6 is for you. The superior aerodynamics are great for riding alone or leading a group. If you are looking for one wheelset to do everything, you’ve found it.
System-Optimised™ Design
A Different Approach To Wheel Design
Tokyowheel System-Optimized™ wheels have distinctly different front and rear rims to maximize performance.
CFD Engineered
Computational Fluid Dynamics
Faster, more aerodynamic wheels as a result of engineering in a computer simulated windtunnel.
Carbon-Strut™ Construction
Unique Carbon Fiber Manufacturing That is Lighter and Stronger
69 folded layers of carbon fiber arranged in a stronger, lighter construction only possible with System-Optimized™ wheels.
DuraHeat-R™ High-Temperature Carbon
Better Braking Performance.
A three part technology for superior braking with carbon rims.
Standard Hubs and Spokes
Tokyowheel™ VAPOR 2 Hubs & Aero Bladed Spokes
Optional DT Swiss Hubs and Pro Spokes
Dt Swiss 2402 Straight Pull Hubset Horizontal Super
One of the most well known names in hubs. DT Swiss components have a long history of quality and high performance. These hubs are compatible with Center Lock® disc rotors, and are available in your choice of either Quick-Release or Thru-Axle (15mm Front, 12mm Rear).
Optional Pro Hubs and Spokes
Tokyowheel™ VAPOR 2 Hubs & Aero Bladed Spokes
Ultralight carbon fiber hubs with an extra-durable magnetic Ring-Ratchet™ and pro level spokes.
UCI Approved
This wheelset has been certified and approved by the UCI (Union Cycliste Internationale), for use in UCI sanctioned road races. These wheels are also certified for use in ITU (International Triathlon Union) sanctioned triathlons.
Detailed Specs
| Weight* | 1615g ~ 1754g (Depending Upon Hub & Spoke Options) |
| Rim Weight* | Front 550g, Rear 600g |
| Rim | 700c Carbon Clincher |
| Tubeless | Compatible |
| Rim Depth | Front 55mm, Rear 65mm |
| Brake Track Width | 25mm |
| Brake Track | Angled |
| Max Width | Front 29mm, Rear 28mm |
| Internal Rim Width | 18mm |
| Valve Balanced | true |
| Carbon Finish | Matte UD Carbon Fiber |
| Spokes | Standard: 2.3mm Aero Bladed, Pro: Sapim CX-Ray |
| Spoke Count | Front: 20, Rear: 24 |
| Spoke Pattern | Front: Radial, Rear: 2x |
| Hub | Standard: VAPOR™ 2, Pro: CARBON VAPOR™, DT Swiss: 240s |
| Free Hub | Shimano/SRAM 9/10/11 Or Campagnolo 9/10/11 |
| Bearings | Standard: 688 6802 TPI Stainless Cartridge, Pro: 6900 6902:15267 Angular-Contact Stainless |
| Rider Weight Limit | 254lbs / 115kg |
| Recommended Tire Pressure | 110 psi |
| Max Tire Pressure | 140 psi |
| Recommended Tire | Continental GP4000s II (23mm x 700c) |
* Wheel weights are subject to a +/- 5% variance.
Warranty & Guarantees
The Best In The Industry
110% Speed Guaranteed
65 Day Test Ride
110% Money-back Guarantee
FREE Worldwide Shipping + Returns!
Guaranteed No Customs Taxes
Up To 3 Year Warranty & 5 Year Crash Replacement
What’s In The Box
All The Accessories You Need
Titanium Quick-Release Skewers (Included with Quick-Release Compatible Hub Options), Nylon Rim Strip, Valve Extensions.
How To Buy
| brands | Tokyowheel |
|---|---|
| Condition |
Reviews
