APC Smart-UPS RM SMT3000RM2U 2700W/3000VA 2U 120V LCD UPS System

This UPS provides backup battery power in the event of a power outage, monitoring and safeguarding your equipment from harmful power conditions, spikes and surges. An automatic green mode ensures you are operating at the highest level of efficiency, and intelligent battery management maximizes performance. Use the intuitive LCD interface and PowerChute Business Edition software to configure UPS settings and monitor usage. With a 2,700-watt power capacity, 10 outlets, and one switchable outlet group this Smart-UPS is ideal for small and medium-sized businesses.

Protects Electronic Equipment from Power Disruptions

Keep your electronic equipment protected through blackouts, brownouts, surges, and other power disturbances with APC Smart-UPS. It provides generous runtime while on battery so you can continue working during medium-length power outages. Providing a greater level of control this UPS has one switchable outlet group that allows individual control separate from the UPS. Allowing the ability to reboot hung devices, program sequenced on and off and non-critical load shedding of equipment.

Automatic voltage regulation (AVR)

Automatic voltage regulation (AVR) adjusts high and low voltages to a safe level, ensuring your equipment has reliable power and preserving the life of the battery. The pure sine wave output while on battery provides the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.

Green Mode Reduces Power Consumption

Operate efficiently with the Smart-UPS green mode, conserving energy without sacrificing any protection when power quality is within optimal levels and power conditioning is not necessary. The UPS will enter and exit green mode automatically, ensuring you are always reducing utility costs, and generating less heat. To help you monitor your energy usage, this UPS has an energy meter that provides actual kilowatt-hours of usage.

Intelligent Battery Management

For easy battery maintenance, this Smart-UPS provides a predictive month and year for when battery replacement is recommended. It also prolongs battery life by regulating the charge voltage according to battery temperature. Detect faulty batteries with the periodic battery self-test and disconnected battery notification.

Bright LCD Interface

Quickly view the UPS utility status thanks to multiple status indicators on the bright, easy-to-read LCD interface. It provides clear, accurate information in multiple language options, and the intuitive navigation keys make it simple to configure settings. A SmartSlot lets you use a network management card to remotely manage and control the UPS.

PowerChute Software Provides Safe System Shutdown

Designed for exceptional usability, PowerChute Business Edition software provides safe system shutdown in the event of an extended power outage while preventing potential data corruption. It’s fast and easy to install, and you can tailor settings to meet your individual needs. Find cost savings by using PowerChute to monitor your equipment’s energy consumption.

What’s in the Box

APC Smart-UPS SMT3000, CD with PowerChute Business Edition software, documentation CD, Smart-UPS signaling RS-232 cable, and USB cable

	SMT750	SMT1000	SMT1500	SMT2200	SMT3000
Power capacity	500 W/750 VA	700 W/1,000 VA	1,000 W/1,440 VA	1,980 W/2,200 VA	2,700 W/3,000 VA
Nominal output voltage	120 V	120 V	120 V	120 V	120 V
Output connections (NEMA)	(6) 5-15R	(8) 5-15R	(8) 5-15R	(8) 5-15R, (2) 5-20R	(8) 5-15R, (2) 5-20R
Switched outlet groups		1	1	1	1
Battery type	Maintenance-free sealed lead-acid battery with suspended electrolyte; leak proof	Maintenance-free sealed lead-acid battery with suspended electrolyte; leak proof	Maintenance-free sealed lead-acid battery with suspended electrolyte; leak proof	Maintenance-free sealed lead-acid battery with suspended electrolyte; leak proof	Maintenance-free sealed lead-acid battery with suspended electrolyte; leak proof
Replacement battery	RBC48	RBC6	RBC7	RBC55	RBC55
Interface ports	Serial (RJ45), USB, and SmartSlot	Serial (RJ45), USB, and SmartSlot	Serial (RJ45), USB, and SmartSlot	Serial (RJ45), USB, and SmartSlot	Serial (RJ45), USB, and SmartSlot
Control panel and audible alarms	Alpha-numeric LCD display with LED status indicators; alarm on battery, distinctive low battery alarm and configurable delays	Alpha-numeric LCD display with LED status indicators; alarm on battery, distinctive low battery alarm and configurable delays	Alpha-numeric LCD display with LED status indicators; alarm on battery, distinctive low battery alarm and configurable delays	Alpha-numeric LCD display with LED status indicators; alarm on battery, distinctive low battery alarm and configurable delays	Alpha-numeric LCD display with LED status indicators; alarm on battery, distinctive low battery alarm and configurable delays
Emergency power off (EPO)	Optional	Optional	Optional	Yes	Yes
Regulatory	UL 1778, CSA	UL 1778, CSA	UL 1778, CSA	UL 1778, CSA	UL 1778, CSA

Technical Specifications
