EVGA DG 85 ATX Computer Case
Availability:
In stock
Key Features
- 3 Year Warranty
- Optimized Airflow Path
- Robust Water Cooling Support
- Cable Management
- Built in Fan Controller + Temperature Sensor
- K-Boost Button
- Removable Fan Filters
- Front and Top Facing Power, Reset Buttons and USB 2.0. Front Facing USB 3.1 Type-C, and HDMI
- Easy Removable Door
- Supports up to 12 SSD/HDD
- GPU Airflow Channel
- Optional Segmented PSU Tray Hides Cables
- Flexible Fan Support
- Easy Access to I/O ports and Clean Cable Output
- Completely Removable PCI-E Brackets
EVGA DG 85 ATX Full Tower Gaming Computer Case, Grey (100-E1-1000-K0)
Introducing the EVGA DG-8 line of full-tower cases. These cases are built for the enthusiast with an optimized airflow path that gives you dedicated cooling fans for your graphics cards, a K-Boost button that automatically boosts fanspeed and CPU/GPU, a built in fan controller and much more. These new line of cases are the ultimate platform for any gaming or graphics enthusiast. With these features and more, it is easy to see how DG means Designed for Gaming!
EVGA DG-87
EVGA DG-86
EVGA DG-85
EVGA DG-84
FEATURES
Optimized Airflow PathDedicated cooling path for graphics cards, giving ultimate cooling performance and increased clockspeeds.
Robust Water Cooling SupportFull support for dual 420mm or 360mm radiators give you ultimate cooling performance, with a dedicated section for mounting reservoir.
Cable ManagementDedicated cable management cutout points lets you keep your system layout clean, improving appearance and airflow.
Built Fan Controller + Temperature SensorBuilt in fan controller lets you select your cooling performance, and monitor the case internal temperature.
K-Boost ButtonControl your performance with EVGA K-Boost! One button boosts GPU and CPU clocks instantly, giving you ultimate control.
Removable Fan FiltersEasy to remove fan filters keeps your system dust free.
Front and Top Facing Power, Reset Buttons and USB 2.0. Front Facing USB 3.1 Type-C, and HDMIEasily power on your system whether it is on the floor or desk, make your PC VR-Ready with front facing HDMI and USB.
Easy Removable DoorFlip a switch to remove the entire door, making assembly as easy as can be.
Supports up to 12 SSD/HDDDedicated mounting locations on back of motherboard and drive bay keep cables out of the way.
GPU Airflow ChannelAdjustable channel to maximize cooling efficiency depending on your GPU setup.
Optional Segmented PSU Tray Hides CablesSlidable tray keeps your system clean and hides Power Supply cables.
Flexible Fan SupportSupports up to 8 140 or 120mm fans.
Easy Access to I/O ports and Clean Cable OutputCables exit on the back of the case, keeping cable management clean, and I/O ports are easily accessed by left door hinge.
Completely Removable PCI-E BracketsRemove brackets to increase airflow or easily pass water cooling tubes.
EVGA DG-8 SERIES COMPARISON CHART
| Case Name | EVGA DG-87 | EVGA DG-86 | EVGA DG-85 | EVGA DG-84 |
| Window Panel | Yes | Yes | Yes | No |
| Finish | Metallic Gunmetal Grey | Gunmetal Grey | Gunmetal Grey | Gunmetal Grey |
| Form Factor Support | mITX/mATX/ATX/E-ATX | mITX/mATX/ATX/E-ATX | mITX/mATX/ATX/E-ATX | mITX/mATX/ATX/E-ATX |
| Max Graphics Cards | 4 | 4 | 4 | 4 |
| I/O Ports (Top) | ||||
| Power | 1 | 1 | 1 | 1 |
| Reset | 1 | 1 | 1 | 1 |
| K-Boost | 1 | 1 | 1 | 1 |
| USB 2.0 | 2 | 2 | 2 | 2 |
| I/O Ports (Front) | ||||
| Power | 1 | 1 | 1 | 1 |
| Reset | 1 | 1 | 1 | 1 |
| K-Boost | 1 | 1 | 1 | 1 |
| USB 3.0 | 2 | 2 | 2 | 2 |
| USB 3.1 Type-C | 1 | 1 | 0 | 0 |
| HDMI | 1 | 1 | 1 | 1 |
| Audio (Headphone) | 1 | 1 | 1 | 1 |
| Audio (Mic) | 1 | 1 | 1 | 1 |
| Storage Support | ||||
| Max SSD/HDD Supported | 12 | 12 | 4 | 4 |
| 2.5in SSD | 12 | 12 | 4 | 4 |
| 3.5in HDD | 8 | 8 | 2 | 2 |
| Fans | ||||
| Fan Controller | Yes (Software+Buttons) | Yes (Software) | No | No |
| Fan Size | 140mm (Default), 120mm (Option) | 140mm (Default), 120mm (Option) | 140mm (Default), 120mm (Option) | 140mm (Default), 120mm (Option) |
| Max Fan Support | Top x 3, Right x 3, Left x 2 | Top x 3, Right x 3, Left x 2 | Top x 3, Right x 3, Left x 2 | Top x 3, Right x 3, Left x 2 |
| Included Fans | Top x 1, Right x 3, Left x 2 | Right x 2, Left x 2 | N/A | N/A |
| Temperature Sensor | Yes | Yes | N/A | N/A |
| LED Display | Yes | Yes | N/A | N/A |
| Water Cooling Bracket | Yes | Yes | N/A | N/A |
| Case Size (LxWxH) | 686x270x642.45mm | 686x270x642.45mm | 686x270x642.45mm | 686x270x642.45mm |
| Individual Shipper Size | 740x372x800mm | 740x372x800mm | 740x372x800mm | 740x372x800mm |
| Case Weight (lb/kg) | 43.2bl/19.6kg | 43.2bl/19.6kg | 37.5lb/17.0kg | 38.4lb/17.4kg |
| Gross Weight | 51.1lb/23.2kg | 51.1lb/23.2kg | 43.4lb/19.7kg | 44.3lb/22.1kg |
