Hikvision DS-7600NI-E1/4P Embedded Plug & Play NVR
Availability:
In stock
PRODUCT HIGHLIGHTS
- 4-Channel NVR with PoE
- Individually Configurable Channels
- Third-Party Network Cameras Supported
- Up to 5MP Resolution Recording
- HDMI and VGA Output at Up to 1080p
- SATA Interface Supporting Up to 4TB
- 2-Way Audio Input; 1x RCA Output
- Configurable Video Input/Output Quality
- HDD Group Management
Hikvision NVR DS-7600NI-E1/4P with PoE Network Video Recorder Plug & Play with updatable firmware Support 6mp IP camera with HDMI and VGA output at up to 1920×1080P Home SecurityÂ
Record video and audio from up to 4 cameras with Hikvision’s 4-Channel NVR, offering plug-and-play PoE interfaces and capable of being used standalone or as part of a comprehensive surveillance system. Main features include multiple recording and playback modes, two-way audio, and HDMI and VGA monitoring output. Record and play back in up to 1080p HD resolution using Hikvision or 3rd-party network cameras. The NVR features a SATA interface supporting up to 4TB HDD.
- Compression
-
- Connect up to 4 network cameras
- Independent configuration for each channel, including resolution, frame rate, and bit rate
- Each channel supports two compression parameters — continuous and event — which can be configured locally and remotely
- Configurable video input/output quality
- Watermark support
- Local Monitoring
-
- Simultaneous HDMI and VGA outputs at up to 1920x1080p resolution
- Multiple screen display in live view
- Adjustable screen display sequence
- Live view screen is switchable in group
- Manual switch and automatic cycle live view
- Adjustable automatic cycle intervals
- Selected live view channel can be shielded
- Motion detection, tamper-proof, video exception alert, and video loss alert functions
- Privacy mask
- PTZ protocols supported: PTZ preset, patrol, and pattern
- Mouse-controllable zoom and PTZ tracing
- HDD Management
-
- Supports 1 SATA disk, up to 4TB
- HDD group management
- HDD property: redundancy, read-only, read/write
- HDD quota management: a different capacity can be assigned to each channel
- Supports S.M.A.R.T and bad sector detection
- Recording, Capture, and Playback
-
- Holiday recording schedule configuration
- Continuous and event video encoding parameters
- 8 recording periods with separated recording types
- Pre-record and post-record for alarm
- Motion detection recording
- Pre-record time for schedule
- Search recorded files and captured photos by event (alarm input/motion detection/VCA)
- Customization tags
- Search and playback by tags
- Lock/unlock recorded files
- Search and playback by channel, type, start time, end time, and more
- Zoom during playback
- Reverse playback for multi-channel display
- Pause, speed up/down, skip forward, skip backward during playback
- Up to 4-channel synchronous playback at 4CIF real time
- Smart playback supported
- Backup
-
- Export video data via USB port
- Export video clips during playback
- Management and maintenance of backup devices
- Alarm and Exception
-
- Alarm for VCA, video loss, motion detection, tampering, HDD Full, HDD Error, Network Disconnected, IP Conflicted, Illegal Login, Recording Exception, and more
- Alarm triggers full screen monitoring, audible warming, notifying surveillance center, sending email, and alarm output
- Automatic restore when system is abnormal
- Other Local Functions
-
- Operation by mouse and remote control
- Three-level user management
- Admin user can create many operating accounts and define their operating permissions, which includes blocked channels
- Operation, alarm exceptions, and information log recording and searching
- Import and export device configuration information
- Network
-
- One self-adaptive 10M/100M/1000M network interface and 4 Plug & Play PoE Interfaces independent PoE network interfaces are provided
- IPv6 supported
- TCP/IP protocol, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, UPnP, NFS, and iSCSI are supported
- TCP, UDP, and RTP for unicast
- Auto/manual port mapping and automatic UPnP discovery
- Remote web browser access by HTTPS ensures high security
- Remote search, playback, download, locking, and unlocking
- Remote import/export of device parameters
- Remote viewing of device status, system logs, and alarm status
- Remote locking and unlocking of control panel and mouse
- Remote HDD formatting and program upgrading
- Remote system restart and shutdown
- Alarm and exception information can be sent to the remote host
- Remotely start/stop recording
- Remotely start/stop alarm output
- Upgrade by remote FTP server is supported
- Remote PTZ control
- Two-way audio
- Embedded WEB server
- Supports access by Ezviz
- Development Support
-
- SDK for Windows and Linux systems
- Source code of software application for demo
- Development support and training for use of application
| IP Video Inputs | 4 channels |
| Two-Way Audio | 1x RCA input (2.0 V p-p, 1 kOhm) |
| Bandwidth | Incoming: 40 Mb/s Outgoing: 80 Mb/s |
| Remote Connection | 128 |
| Monitoring Outputs | 1x HDMI, 1 VGA
Resolution (via either output): 1920 x 1080p at 60 Hz, 1600 x 1200 at 60 Hz, 1280 x 1024 at 60 Hz, 1280 x 720 at 60 Hz, 1024 x 768 at 60 Hz |
| Recording Resolution | 5 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| Frame Rate | Main Stream: 50 fps (P) / 60 fps (N) Sub-Stream: 50 fps (P) / 60 fps (N) |
| Audio Output | 1x RCA (Linear, 1 kOhm) |
| Synchronous Playback | 4 channels |
| Live View / Playback | 5 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| Decoding | 4-channels at 1080p |
| SATA | 1x SATA interface supporting 4 TB |
| Network Interface | 1x RJ45 10/100/1000 Mb/s self-adaptive Ethernet interface |
| USB Interface | 1x USB 2.0 and 1x USB 3.0 |
| Alarm Input | 4 channels |
| Alarm Output | 1 channel |
| PoE Interfaces | 4 Plug & Play PoE Interfaces independent 100 Mb/s PoE network interfaces |
| Maximum Power | 50 W Consumption without hard disk and PoE: ≤ 10W |
| Supported Standards | AF and AT |
| Power Supply | 100-240 VAC |
| Operating Temperature | 14 to 131°F (-10 to 55°C) |
| Operating Humidity | 10 to 90 % |
| Chassis | 19″ rack-mounted 1U chassis |
| Dimensions | 12.4 x 9.1 x 1.8″ (31.5 x 23 x 4.6 cm) |
| Weight | ≤ 2.2 lb (1 kg) (without HDD) |
| Packaging Info | |
|---|---|
| Package Weight | 5.0 lb |
| Box Dimensions (LxWxH) | 19.2 x 11.5 x 3.4″ |
