IN WIN 509 ATX Full Tower Computer Case
Availability:
In stock
Specifications
- Dimensions (mm) 235 x 578 x 527 (W x D x H)
- Material Steel, tempered glass, plastic
- Available colours Black, or black and red (ROG version)
- Weight 14kg
- Front panel Power, reset, 4 x USB 3.0, stereo, microphone
- Drive bays 1 x external 5.25in, 5 x 3.5in/2.5in, 4 x 2.5in
- Form factor(s) E-ATX, ATX, micro-ATX, mini-ITX
- Cooling 2 x 140mm or 3 x 120mm front fan mounts (fans not included), 3 x 120mm side fan mounts (fans not included), 2 x 140mm or 3 x 120mm internal fan mounts (fans not included), 1 x 140mm/120mm rear fan mount (fans not included), 1 x 140mm/120mm bottom fan mount (fan not included)
- CPU cooler clearance 188mm
- Maximum graphics card length 370mm
- Extras Removable dust filter, RGB LED cable
IN WIN 509 Tempered Glass ATX Full Tower Computer Case ATX PS2 / EPS 12V Power Supply
The In Win 509’s front and side panel are both composed of tempered glass which comes with an RGB logo that’s powered by a 4-pin connector (compatible with motherboards with RGB headers) to provide users with an incredible visual experience. Packed full of features such as multifunctional bracket design, versatile liquid cooling options, outstanding cooling performance and large graphics card support, the 509 offers unlimited creativity in a simple, yet elegant chassis.
Specifications
| Model | 509 |
|---|---|
| Color | Black/Gray, Black/Red |
| Case Type | Full Tower |
| Case Material | SECC, Tempered Glass |
| M/B Compatibility | E-ATX (12″ x 13″), ATX, Micro-ATX, Mini-ITX |
| Expansion Slots | PCI-E x 8 |
| Maximum Compatibility | VGA Card Length: 370mm CPU Heatsink Height: 188mm |
| Front Ports | 4 x USB 3.0 HD Audio |
| External Drive Bays | 1 x 5.25″ |
| Internal Drive Bays | 5 x 2.5″/3.5″ – 3 x EZ-Swap 4 x 2.5″ |
| Thermal Solution Compatibility | 3 x 120/2 x 140mm Front Fan / 360mm Radiator (Remove bottom HDD bracket) 3 x 120/2 x 140mm Internal Fan / 360mm Radiator (Remove bottom HDD bracket) 1 x 120/140mm Rear Fan / 140mm Radiator 1 x 120/140mm Bottom Fan (Remove the HDD bracket) |
| Power Supply Compatibility | PSII: ATX12V and EPS12V – Length up to 230mm |
| Product Dimension (H x W x D) |
527mm x 235mm x 578mm 20.7″ x 9.3″ x 22.8″ |
| Product Dimension (H x W x D) with screw height |
527mm x 245mm x 578mm 20.7″ x 9.6″ x 22.8″ |
| Package Dimension (H x W x D) |
670mm x 635mm x 355mm 26.4″ x 25″ x 14″ |
| Net Weight | 14kg / 30.9lb |
| Gross Weight | 16.6kg / 36.6lb |
| * In Win products comply with RoHS regulation. * Specifications may vary based on different regions. |
|
