Features

– 1 touch a-second user recognition
– Fingerprint reader with durable and highly accurate ZK optical sensor
– Stores 3000 templates, 5,000 cards and 30,000 transactions
– Reads Fingerprint and/or Card
– Optional integrated smart card reader
– Built-in Serial and Ethernet ports
– Tamper-proofs switch and alarm outputs
– Request-to-exit and alarm contacts
– Audio-Visual indications for acceptance and rejection of valid/invalid fingers

Specifications

Fingerprint Capacity: 1500 templates
ID card Capacity: 5000
Transaction Capacity: 30,000
Sensor: ZK Optical Sensor
Algorithm Version: ZK Finger v10.0
Communication: RS232/485, TCP/IP， USB-host
Access Control Interface for: 3rd party electric lock, door sensor, exit button, alarm, Door Bell
Wiegand Signal: Output and Input
Display: TFT LCD Screen
Standard function: ID card, Webserver, DLST
Optional function: Mifare card
Power Supply: 12V DC
Operating Temperature: 0 ℃- 45 ℃
Operating Humidity: 20%-80%

TFT Color Screen Audio-visual indication for acceptance and rejection of valid/invalid fingerprints. More simple and convenient operation.

Slim and Elegant Design Sleek and slim design for narrow spaces.

Fast and Accurate Fingerprint Algorithm 1 touch a-second user recognition. Store 3,000 fingerprint templates, 30,000 cards and 100,000 transactions.

Full Access Control Features Anti-passback. Webserver. Access control interface for 3rd party electric lock, door sensor, exit button, alarm and doorbell

Easy Installation and Connectivity Wiegand input & output. Network interface by TCP/IP or RS485

Easy Operation and Management Work without computer. Buzzer, 4×4 keypads and door bell. Built-in serial and Ethernet ports. Built-in USB port allows for manual data transfer
